12 Pack 20 x 260mm Chemset Anchor Studs & Concrete Anchor Kit

$260.00

In stock

This premium 12-pack of heavy-duty ChemSet anchor studs delivers an elite high-strength structural chemical fastening solution engineered specifically for anchoring heavy car hoists, parking storage lifts, and heavy workshop machinery into concrete foundations. Designed to interface seamlessly with chemical injection adhesive resins, these M20 x 160mm studs establish a permanent, vibration-resistant bond within the concrete matrix. Manufactured from high-tensile structural carbon steel and finished with an industrial protective coating, this comprehensive kit allows commercial garages, automotive technicians, and home workshop builders to secure full-capacity automotive lifts with the absolute highest level of safety and structural integrity.

  • Chemical Adhesive Bonding — Engineered specifically to work with chemical injection resins to create a continuous, tension-free bond within the concrete borehole.
  • High-Tensile Structural Capacity — M20 structural studs provide massive vertical pull-out resistance and extreme shear load holding power under maximum vehicle lift weight.
  • Zero Stress Expansion — Unlike mechanical wedge anchors, chemical anchoring applies zero internal expansion pressure to the concrete, making it safe for edge installations.
  • Complete Fastener Kit — Supplied as a complete 12-pack matrix with matching heavy structural flat washers and hex nuts to easily fit multi-point 2-post and 4-post hoist column base bases.
Delivery Information

Delivery time varies by location and stock availability. Contact us if you need freight pricing or lead time before ordering.

Warranty & Returns

Warranty and returns depend on the product and manufacturer terms. Check the product details or contact us before purchase if you need clarification.

Overview

Unlike standard mechanical dyna-bolts that rely entirely on localized metal friction and can introduce severe outward expansion stress—potentially fracturing older concrete slabs or failing near edges—this professional ChemSet chemical anchor kit establishes a molecular, fused connection. It is engineered explicitly for high-throughput commercial mechanical repair stations, independent tire networks, heavy-duty 4WD modification centers, and home enthusiast garages requiring an unyielding hoist mounting layout, meaning it is the premier choice for anchoring heavy vehicle lifts but requires careful borehole cleaning and proper chemical resin curing steps during installation.

Key Features

  • Chisel-Point Stud Design — Every M20 stud is formed with a specialized clean angle chisel tip, allowing easy insertion and efficient rotation to perfectly mix resin compounds within the drilled hole.
  • Vibration-Dampening Integration — The chemically cured synthetic polymer matrix absorbs the heavy cyclical vibrations, torque kicks, and operational pressure frequencies of automotive hoists, preventing loosening over time.
  • Industrial Anti-Corrosion Shielding — Treated with a thick protective surface coating to completely insulate the critical structural threads against aggressive workshop moisture, oils, and chemical spills.
  • Deep-Set M20 x 160mm Specification — Designed with an optimal length profile to capture deep subsurface concrete load capacity, ensuring total structural stability under extreme vertical leverage forces.

Before You Order

Installation requires a fully cured, structural concrete foundation pad meeting your specific vehicle hoist's technical strength requirements. Boreholes must be drilled perfectly vertical, brushed cleanly, and thoroughly evacuated of all masonry dust and grit using a blow pump prior to injecting adhesive resin. Always follow the specific chemical adhesive manufacturer's technical guide regarding ambient temperature curing times before applying torque to the hex nuts.

What's Included

  • Twelve heavy-duty high-tensile M20 x 160mm chisel-point chemical anchor studs
  • Twelve matching heavy-duty structural steel hex nuts
  • Twelve matching heavy-duty structural steel flat washers

Please note that liquid chemical injection adhesive resins, applicator guns, masonry wire hole brushes, and vehicle hoist units are sold separately.

To establish a fully certified, high-capacity mechanical or storage bay configuration, consider combining this premium chemical anchor kit with our clear-floor 2-post car hoists, heavy four-post parking lifts, or base support concrete reinforcement plates. Contact our technical support team for bulk commercial trade packaging options and immediate shipping direct to your workshop.

3-year warranty. In stock and shipped from Wendouree, Victoria.

Questions? Call 1300 090 266, Monday–Friday 8am–3pm AEST.
