YL-9FW Twin Parking Storage Hoist 4 Ton Twin Storage Car Hoist Extra High Lift 2200
YL-9FW Twin Parking Storage Hoist 4 Ton Twin Storage Car Hoist Extra High Lift 2200 - Image 2
YL-9FW Twin Parking Storage Hoist 4 Ton Twin Storage Car Hoist Extra High Lift 2200 - Image 3
YL-9FW Twin Parking Storage Hoist 4 Ton Twin Storage Car Hoist Extra High Lift 2200 - Image 4

YL-9FW Twin Parking Storage Hoist 4 Ton Twin Storage Car Hoist Extra High Lift 2200

Product Status: [aaw_product_status]

Original price was: $8,300.00.Current price is: $8,100.00.

Calculate shipping
Calculate shipping

All Our Hoists Come With A 3 Year Warranty

Extra High 4 Post Storage Hoist

FEATURES:
  • Double your parking space
  • Extra High Lift Of 2200mm Clearance Height With Hoist Unloaded (no Vehicle On Hoist)
  • Perfect for storing vehicles
  • Electrical Control system
  • Removable Ramps
  • Safety
  • Mechanically locks each interval – (safety locks every 100mm apart)
  • Anti-surge valve
  • Cable slack locks
  • 240vt Hydraulic Motor (15amp)  Uses AW46 Grade Hydraulic Oil (12Litres) not included.
  • Warranty
  • 5 years (structure) + 1 year (electrical and hydraulics)
  • Options
  • Oil trays (7 oil trays cover the entire length of one set of runaways, so 14 will cover both), Caster Wheel Kit, Infill kit, Jacking Tray, Rolling Jacks
SPECIFICATIONS:
  1. Capacity-  4000kg
  2. L x W x H – 4445 x 5058 x 2476mm
  3. Power- 240v- (15amp plug)
  4. Lifting Time- 50s
  5. Inside Width Between Columns-  4568mm
  6. Maximum Lifting Height- 2200mm
  7. Maximum Lifting Height On Top Lock- 2130mm
  8. Maximum Lifting Height Locked With Car On Hoist- 2030mm
  9. Clearance Under Runways Car On Hoist- 1905mm
  10. Clearance Under Runways Hoist Unloaded- 2025mm
  11. Overall Width- 5058mm
  12. Overall Length (incl. ramps)- 55262.5mm
  13. Overall Length (excl. ramps)-  4445mm
  14. Platform Width- 475mm
  15. Width Between Platforms- 958mm
  16. Platform Length- 4200mm
  17. Drive Through Clearance- 4836mm

Carton Dimensions :

Packages size 1:  weight 720KGS,  dimensions 430 x 56 x 73cm

Packages size 2:  weight 740KGS,  dimensions 530 x 56 x 52cm

Installation Manual
