YL-11FW Twin Car Parking Storage Hoist 5 Ton

Product Status: In Stock

$8,200.00

Calculate shipping
FEATURES:
  • Double your parking space
  • Perfect for storing vehicles
  • Electrical Control system
  • Removable Ramps
  • Safety
  • Mechanically locks each interval
  • Anti-surge valve
  • Cable slack locks
  • Warranty
  • 5 years (structure) + 1 year (electrical and hydraulics)
  • Options
  • Oil trays, Caster Wheel Kit, Infill kit, Rolling Jack, Jacking plate
SPECIFICATIONS:
  1. Capacity                                             5000kg (total)
  2. Lock Release                                    Mechanical
  3. Power                                                  240v (10amp plug) AW32 Grade Hydraulic Fluid (12Litres)
  4. Column Height                                2312mm
  5. Lifting Height                                  1971mm
  6. Clearance Under Runways         1834mm
  7. Overall Width                                  5030.5mm
  8. Overall Length (incl. ramps)     5632mm
  9. Overall Length (excl. ramps)     4488mm
  10. Platform Width                               475mm
  11. Width Between Platforms          955mm
  12. Platform Length                             4200mm
  13. Drive Through Clearance           4655.5mm

Carton Dimensions :

  1. 422 x 56 x 73cm  1000kgs
  2. 533 x 56 x 52cm  1000kgs

Total Weight 2000kgs



Pg 1 TO 36                      Pg 37 TO 72

CLICK ON ABOVE FOR USER MANUAL
