DS-806A Car Tyre Changer Suitable For 10 to 24"


Availability: 20 in stock

Calculate shipping

Application range:
Applicable for changing and inflating car tyre whose rim diameter is between 10”-24”.
Product features:
Adopting semi-automatic lateral swinging arm and two-side arms to change tyre.

Technical parameters:

  • Also suitable for motorcycle rims by purchasing optional motorcycle adapters
  • Rim clamp from outside:10″-22″
  • Rim clamp from inside:12″-24″
  • Max. wheel diameter:1040 mm
  • Tire width:3″-15″
  • Working pressure:8~10 bar
  • Bead breaking force: 2500kg
  • Voltage:240v
  • Power:1.1kw
  • Machine weight:186kg

Machine functions:

  1.  Adjustable mobile slider, suitable for different rim ranges.
  2. Has four automatic alignment gripping jaws with synchronizing function and automatic self centering  when gripping the rim from outside to inside.
  3. The working head is surface plated in hard chrome to ensure long lasting
  4. Has self centering and fine adjustment function to allow easy and smooth operation of the tyre changer.
  5. All tools touching rim directly are all equipped with protector, these protectors ensure no damage to the rim.
  6. Low noise rating.
  7.  Super strong and made to last


Dimensions:- 111cm x 89cm x 86cm

Weight:- 186kgs

Please Note We also have motorcycle rim adapters available to suit this tyre changer
